Product description:

The 8Bands Waterproof Adjustable High Power Phone Jammer for Prison is specially customized to accommodate a fully integrated broad band jamming system which provides the ultimate solution for Prison Military and Police convoys or VIP protection. The 8 modules are controlled separately and they also can work simultaneously.

Each module with antenna can be used as a single jammer. The prison jammer is waterproof and portable, the jammer case is our patent design, it can be installed in desert and more rain of bad weather. The Frequency band is optional. And the high power jammer is with excellent heat dispersion.

Applications
Products Application Fields

High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.

Specification

• Affect frequency:

CH-CDMA: 850-960MHz
CH-GSM: 920-960MHz
CH-DCS: 1800-1880MHz
CH-PCS: 1900-1990MHz
CH-3G: 2110-2170MHz
CH-4G LTE: 725-770MHz(US) or 790-826MHz(EU)
CH-4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU)

CH-5G LTE :3500-3600 MHz

CH-5G LTE :3600-4200 MHz
CH-WiFi: 2400-2500MHz

• Total output power: 500W
• Jamming range: up to  100-500m, the jamming radius still depends on the strength signal in given area
• Power supply: AC110-240V,
• Omni-Directional Antenna
• Housing: Waterproof & shockproof design suitable indoor or outdoor use
• Dimension: 56*46*57 cm
• Full set weight: 45.00kg

Advantages and Features

• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.

Support below function:

- On/Off remote control and other options is available
- Light signals
-On/off state
-State of major failure.
- Working temperature:-20°c to +60°
- Wall mounting kit

Machine Monitor software function:

· Remote control switches of each machine.
· Remote viewing each machine working state.
· The power output of each machine remote adjustment.
· Remote viewing offline log of each machine.
· Mail receiving each machine working state.
· The system can set permissions to log on.
